5V0-23.20 VMware vSphere with Tanzu Specialist Questions and Answers

Authenticating Using kubectl

In vSphere with Tanzu, authentication is performed using vCenter Single Sign-On. You run the command kubectl vsphere login to authenticate a user through vCenter Single Sign-On to Kubernetes clusters.

kubectl vsphere login --server -u

The --insecure-skip-tls-verify flag is required if the certificate presented by the vSphere with Tanzu control plane is not trusted by the client machine. The control plane is signed by the vCenter Server VMware CA by default. You can replace the control plane certificate with a trusted certificate if needed. Alternatively, install the vCenter Server VMware CA root certificate into your client machine to remove the need for the --insecure-skip-tls-verify flag.

For some parts of your application (for example, frontends) you may want to expose a Service onto an external IP address, that's outside of your cluster.

Kubernetes ServiceTypes allow you to specify what kind of Service you want. The default is ClusterIP.

As a vSphere administrator, you can replace the certificate for the virtual IP address (VIP) to securely connect to the Supervisor Cluster API endpoint with a certificate signed by a CA that your hosts already trust. The certificate authenticates the Kubernetes control plane to DevOps engineers, both during login and subsequent interactions with the Supervisor Cluster.

Prerequisites

Verify that you have access to a CA that can sign CSRs. For DevOps engineers, the CA must be installed on their system as a trusted root.

Procedure

• In the vSphere Client, navigate to the Supervisor Cluster.
• Click Configure then under Namespaces select Certificates.
• In the Workload platform MTG pane, select Actions > Generate CSR.
• Provide the details for the certificate.
• Once the CSR is generated, click Copy.
• Sign the certificate with a CA.
• From the Workload platform MTG pane, select Actions > Replace Certificate.
• Upload the signed certificate file and click Replace Certificate.
• Validate the certificate on the IP address of the Kubernetes control plane.

The Cloud Native Storage server resides in vCenter Server:

• Provisions and manages life cycle operations for container volumes

• Creates First Class Disks (FCDs) to support the container volumes

• First Class Disks exist as .vmdk and -flat.vmdk files on a vSphere datastore •

Integrates with storage policy based management (SPBM) for the placement of disks

A First Class Disk (FCD) is also called an improved virtual disk. It is a named virtual disk that is unassociated with a VM. These disks reside on a VMFS, NFS, or vSAN datastore and support container volumes.

Storage policy based management (SPBM) is a vCenter Server service that supports provisioning of persistent volumes according to specified storage requirements. After provisioning, the service monitors compliance of the volume with the required policy characteristics.

As a vSphere administrator, you can enable the Workload Management platform on a vSphere cluster by configuring the vSphere networking stack to provide connectivity to workloads. A Supervisor Cluster that is configured with vSphere networking supports the deployment of Tanzu Kubernetes clusters created by using the Tanzu Kubernetes Grid Service. It does not support running vSphere Pod or using the embedded Harbor Registry.

Static IPs for Kubernetes control plane VMs

Block of 5A block of 5 consecutive static IP addresses to be assigned to the Kubernetes control plane VMs in the Supervisor Cluster.
