We can use scatter plots to visualize relationships between numerical variables!

In Tableau, you create a scatter plot by placing at least one measure on the Columns shelf and at least one measure on the Rows shelf (Total 2 minimum). If these shelves contain both dimensions and measures, Tableau places the measures as the innermost fields, which means that measures are always to the right of any dimensions that you have also placed on these shelves. The word "innermost" in this case refers to the table structure.

 ( Simple Scatter Plot)

 (Matrix of Scatter Plots)

A scatter plot can use several mark types. By default, Tableau uses the shape mark type. Depending on your data, you might want to use another mark type, such as a circle or a square. For more information, see Change the Type of Mark in the View.

To create a scatter plot, follow the steps below:

In fact, the opposite of this is true.

Trick : Whenever you think of joins -> Think that after the join is created, we get 1 single flat combined (joined) table. This flat combined table is created prior to us creating our visualizations. This happens at the physical layer.

If you ever think about relationships, know that all tables will remain distinct and separate, and relationships sit at the logical layer. At run time, when you bring in the dimensions and measures to create your viz, Tableau very smartly creates the necessary joins, relates the tables and sends queries to these tables to get the resultant data back in the most meaningful way possible. This allows you to focus on using your data and revealing insights from it and focus less on the data preparation aspect!

Refer to logical layer vs physical layer from the official documentation: https://help.tableau.com/current/server/en-us/datasource_datamodel.htm

Top of Form

The correct answer is Toggle the highlighting ON/OFF. If selected, whichever value you choose from this legend will be highlighted in the view. However, if it is deselected, then even if you choose a value in the Legend, it will NOT be highlighted.

See below:

Chart, bar chart Description automatically generated

Bottom of Form
