Professional-Cloud-Security-Engineer Google Cloud Certified - Professional Cloud Security Engineer Questions and Answers

The Resource Location Restriction organization policy constraint ensures that business data is stored in specific geographic locations, which is critical for compliance with regulatory requirements.

Organization Level: Setting the constraint at the organization level ensures that all resources within the organization, including those in different folders or projects, adhere to the location restrictions. This provides a unified policy application across the entire organization, ensuring compliance with regulatory requirements.

Policy Application: The policy will propagate down the resource hierarchy, ensuring that all relevant services within the organization comply with the specified data residency requirements.

This approach provides centralized control and simplifies the management of data residency constraints.

References

Organization Policy Service Documentation

https://cloud.google.com/confidential-computing/confidential-vm/docs/creating-cvm-instance#considerations

Confidential VM does not support live migration. You can only enable Confidential Computing on a VM when you first create the instance. https://cloud.google.com/confidential-computing/confidential-vm/docs/creating-cvm-instance

Use Cloud Data Loss Prevention (DLP) with cryptographic hashing:

Cloud DLP allows you to de-identify sensitive data using several techniques, including cryptographic hashing.

Choose a suitable hashing algorithm like SHA-256 for non-reversible anonymization.

This method converts the original data into a fixed-length hash that does not preserve the original data's format or character set.

Set up a Cloud DLP job to scan your data sources, identify PHI, and apply the cryptographic hashing transformation.

References:

Cloud DLP Overview

De-identification with Cloud DLP

https://cloud.google.com/storage/docs/public-access-prevention

Public access prevention protects Cloud Storage buckets and objects from being accidentally exposed to the public. If your bucket is contained within an organization, you can enforce public access prevention by using the organization policy constraint storage.publicAccessPrevention at the project, folder, or organization level.

To monitor and get notified in case the script causing the Compute Engine instance to crash is executed again, you should create an Alerting Policy in Stackdriver (now known as Google Cloud Monitoring). The Process Health condition can be set to monitor the number of executions of the script and ensure it remains below the desired threshold. By enabling notifications, you will be alerted if this threshold is exceeded.

Step-by-Step:

Log Script Executions: Ensure that the script execution is logged.

Create a User-Defined Metric: Go to Google Cloud Console > Logging > Logs-based Metrics, and create a new user-defined metric that counts the number of times the script executes.

Set Up Alerting Policy:

Navigate to Google Cloud Console > Monitoring > Alerting.

Click on “Create Policy”.

Add a condition and select “Logs-based Metric”.

Configure the condition to trigger when the number of script executions exceeds the threshold.

Configure Notifications: Add notification channels (email, SMS, etc.) to the alerting policy.

Save and Test: Save the policy and test to ensure notifications are received when the script is executed beyond the threshold.

References:

Google Cloud Logging User-defined Metrics

Google Cloud Monitoring Alerting Policies

When creating a secure container image, it is essential to follow best practices to minimize vulnerabilities and ensure the container operates as intended. Here are the two key practices:

Package a Single App as a Container: By packaging only a single application within a container, you reduce complexity and potential attack surfaces. This practice aligns with the principle of single responsibility, ensuring each container has a clear and focused purpose.

Remove Any Unnecessary Tools: Any additional tools or software that are not required by the application should be removed from the container image. This minimizes the number of potential vulnerabilities and reduces the attack surface. A minimal container image also leads to smaller image sizes and faster deployment times.

These practices contribute to creating a more secure and efficient container image.

References

Container Security Best Practices

Securing Container Images

Here are the permissions available to organizationRoleAdmin

iam.roles.create

iam.roles.delete

iam.roles.undelete

iam.roles.get

iam.roles.list

iam.roles.update

resourcemanager.projects.get

resourcemanager.projects.getIamPolicy

resourcemanager.projects.list

resourcemanager.organizations.get

resourcemanager.organizations.getIamPolicy

There are sufficient as per least privilege policy. You can do user management as well as auditing.

https://cloud.google.com/iam/docs/understanding-custom-roles

Define Trusted Image Projects:

Identify the project or projects where your trusted operating system images are stored.

Ensure these images meet your organization’s security requirements and are regularly updated to mitigate vulnerabilities.

Create an Organization Policy:

Navigate to the Organization Policies page in the Google Cloud Console.

Create a policy constraint that restricts the creation of boot disks to only those images stored in your trusted image project(s).

The policy constraint to use is constraints/compute.trustedImageProjects.

Apply the Policy:

Apply this organization policy at the appropriate level (organization, folder, or project) to enforce that all new VM instances use images from the trusted repository.

This ensures consistency in the security posture across all projects within the organization.

Monitor Compliance:

Regularly monitor the compliance with this policy using audit logs and other monitoring tools.

Update the trusted images as necessary to ensure they remain secure and compliant with your security standards.

References:

Organization Policy Service

Trusted Image Projects Constraint

Cloud NAT Service: Use Cloud NAT (Network Address Translation) to allow VM instances without external IP addresses to access the internet securely.

Configuration: Configure Cloud NAT for the subnets containing your VM instances. This setup allows the VMs to initiate outbound connections to the internet for updates and other necessary communications.

Security Compliance: By using Cloud NAT, you adhere to the security policy of not assigning external IP addresses to VMs while still enabling necessary internet connectivity. Cloud NAT provides a secure method for outbound internet traffic without exposing VMs directly to the public internet. References:

Google Cloud - Cloud NAT Overview

Google Cloud - Configuring Cloud NAT

This approach allows you to leverage your existing on-premises PKI infrastructure while minimizing its impact and manual processes. By creating a subordinate CA in Google’s Certificate Authority Service, you can automate the process of issuing certificates for your HTTP load balancer frontends. This solution scales well as the number of load balancers increases.

Objective: Quickly recover a deleted service account used for data transfers.

Solution: Use the undelete command available in the gcloud command-line tool to recover the service account.

Steps:

Step 1: Open the Cloud Shell in the Google Cloud Console.

Step 2: Run the following command to list the deleted service accounts:

gcloud iam service-accounts list --filter="deleted: true"

Step 3: Identify the name and ID of the deleted service account.

Step 4: Use the undelete command to recover the service account:

gcloud iam service-accounts undelete [SERVICE_ACCOUNT_ID]

Step 5: Verify that the service account has been restored and reassign any necessary permissions.

By using the undelete command, you can quickly restore the service account and resume application functionality without compromising security.

References:

Restoring a Deleted Service Account

gcloud iam service-accounts undelete

The Standard Tier network only provides regional load balancing, while the Premium Tier supports global load balancing with a single anycast IP address. To distribute requests across multiple regions, you need to use the Premium Tier and update the load balancer configuration accordingly.

Steps:

Upgrade to Premium Tier: Update the load balancer to use the Premium Tier network in the Google Cloud Console.

Add New Instance Group: Add the instance group in the new region (us-east-2) to the backend configuration of the existing load balancer.

Verify Configuration: Ensure that the frontend configuration of the load balancer uses a single external IP address for global distribution.

References:

Google Cloud: Global load balancing

https://cloud.google.com/resource-manager/docs/organization-policy/restricting-domains#setting_the_organization_policy

The domain restriction constraint is a type of list constraint. Google Workspace customer IDs can be added and removed from the allowed_values list of a domain restriction constraint. The domain restriction constraint does not support denying values, and an organization policy can't be saved with IDs in the denied_values list. All domains associated with a Google Workspace account listed in the allowed_values will be allowed by the organization policy. All other domains will be denied by the organization policy.

Enable VPC Service Controls:

VPC Service Controls help mitigate the risk of data exfiltration by allowing you to define a security perimeter around GCP resources.

Set up a service perimeter around your BigQuery project to restrict data access to within the defined perimeter.

Create Access Levels:

In the Google Cloud Console, navigate to the Access Context Manager.

Define access levels based on IP address conditions, specifying the authorized source IP addresses that are allowed to access your BigQuery resources.

These access levels are used to enforce policies that restrict who can access your sensitive data based on their IP addresses.

Apply Service Perimeter with Access Levels:

Apply the created access levels to the service perimeter to ensure that only requests originating from the specified IP addresses are able to access BigQuery tables.

This setup ensures that the sensitive PII data is not accessible from unauthorized IP addresses, reducing the risk of data exfiltration.

References:

VPC Service Controls

Access Context Manager

Defining Access Levels

”This encryption method is reversible, which helps to maintain referential integrity across your database and has no character-set limitations.” https://cloud.google.com/blog/products/identity-security/take-charge-of-your-data-how-tokenization-makes-data-usable-without-sacrificing-privacy

https://cloud.google.com/dlp/docs/pseudonymization

FPE provides fewer security guarantees compared to other deterministic encryption methods such as AES-SIV. For these reasons, Google strongly recommends using deterministic encryption with AES-SIV instead of FPE for all security sensitive use cases. Other methods like deterministic encryption using AES-SIV provide these stronger security guarantees and are recommended for tokenization use cases unless length and character set preservation are strict requirements—for example, for backward compatibility with a legacy data system.

When using Google Cloud's Platform-as-a-Service (PaaS) offerings like App Engine, Google manages the infrastructure, including the underlying OS, runtime, and scaling. However, securing the application code itself, such as defending against cross-site scripting (XSS) and SQL injection (SQLi) attacks, remains the responsibility of the user. This involves implementing secure coding practices, validating inputs, and employing appropriate security measures within the application.

References:

Google Cloud: Shared responsibility model

App Engine security

Security Command Center (SCC) in Google Cloud provides several features to help organizations detect and respond to security threats and misconfigurations.

Event Threat Detection: This feature continuously monitors and analyzes system logs to detect potential threats such as crypto mining. It uses machine learning and threat intelligence to identify suspicious activities and generate alerts.

Security Health Analytics: This feature helps identify common misconfigurations and compliance violations that could impact security. It provides visibility into security posture and helps remediate issues related to misconfigurations in your Google Cloud environment.

By using both Event Threat Detection and Security Health Analytics, you can effectively monitor for crypto mining activities and detect common misconfigurations that could compromise security.

References

Security Command Center Documentation

Event Threat Detection

Security Health Analytics

To ensure user-uploaded comments and product reviews do not include sensitive data before publication, use the Cloud Data Loss Prevention (DLP) API.

Enable DLP API:

Go to the Cloud Console and navigate to APIs & Services > Library.

Search for "Data Loss Prevention API" and enable it.

Configure DLP API:

Create an inspection template specifying the types of sensitive data to detect.

Set up de-identification templates if you want to redact or mask sensitive data.

Implement DLP in Application:

Use the Google Cloud DLP Client Library for the desired programming language.

Send the text data to the DLP API for inspection before saving or publishing.

from google.cloud import dlp_v2 dlp_client = dlp_v2.DlpServiceClient() parent = f"projects/{project_id}" item = {"value": "User comment text here"} inspect_config = {"info_types": [{"name": "PERSON_NAME"}, {"name": "CREDIT_CARD_NUMBER"}]} response = dlp_client.inspect_content(parent=parent, inspect_config=inspect_config, item=item)

References:

Cloud Data Loss Prevention API Documentation

DLP API Client Libraries

Objective: Ensure VMs can access Cloud Storage without reaching the public internet.

Solution: Enable Private Google Access on the VPC network, allowing VMs with only internal IP addresses to access Google APIs and services privately.

Steps:

Step 1: Open the Google Cloud Console.

Step 2: Go to the VPC Network section.

Step 3: Select the relevant VPC network and subnet.

Step 4: Enable Private Google Access for the subnet.

Private Google Access ensures that instances can access Google APIs and services (such as Cloud Storage) over a private network connection, without requiring a public IP address.

References:

Configuring Private Google Access

Best Practices for Secure Access

To enforce access control policies for applications and resources in Google Cloud, the recommended service is Identity-Aware Proxy (IAP).

Identity-Aware Proxy (IAP):

IAP allows you to control access to your applications and resources based on the identity of the user and the context of the request. It integrates with IAM to provide fine-grained access control, ensuring that only authorized users can access specific resources.

IAP helps enforce security policies at the application layer, providing an additional layer of protection beyond traditional network-based security measures.

References

Identity-Aware Proxy documentation

To enforce private connectivity between on-premises hosts and Google Cloud APIs while optimizing for cost and operational efficiency, using a dedicated or Partner Interconnect is the best solution. This setup ensures a reliable, high-bandwidth connection with private IP addressing.

Choose Interconnect Type: Decide between Dedicated Interconnect and Partner Interconnect based on your bandwidth needs and proximity to Google Cloud locations.

Set Up Interconnect:

For Dedicated Interconnect, order circuits through the Google Cloud Console.

For Partner Interconnect, select a supported service provider and order the connection through them.

Configure VPC and Private Google Access:

In your VPC, enable Private Google Access to allow on-premises hosts to access Google APIs privately.

Go to "VPC network" -> "Private Google Access" and enable it for your subnets.

Establish Connectivity: Work with your network team and (if applicable) your Partner Interconnect provider to set up the physical and logical connections.

Test Connectivity: Verify that on-premises hosts can reach Google Cloud services using private IP addresses.

References:

Google Cloud Interconnect Overview

Configuring Private Google Access

Use Google Shielded VM including secure boot Virtual Trusted Platform Module (vTPM) and integrity monitoring: Shielded VMs provide verifiable integrity of the VM by ensuring that it was not tampered with or compromised at the boot level. They use features like Secure Boot, vTPM, and integrity monitoring to detect and prevent malicious changes to the VM's operating system and firmware.

Activate Confidential Computing: Confidential Computing provides a secure environment for processing sensitive data. It uses hardware-based enclaves to protect data in use by ensuring it cannot be accessed by the underlying host or any other unauthorized entity. By leveraging Intel SGX or AMD SEV, it ensures that data remains encrypted even when it is being processed.

Enforce these actions by using organization policies: Organization policies can enforce the use of Shielded VMs and Confidential Computing across your organization. This ensures that all VMs comply with these security measures without requiring manual configuration for each VM.

References

Shielded VMs documentation

Confidential Computing documentation

Organization Policies documentation

Customer-Managed Encryption Keys (CMEK):

CMEK allows you to manage encryption keys using Cloud Key Management Service (KMS). This gives you control over the lifecycle of the keys, including rotation, destruction, and auditing.

Set up a Cloud KMS key ring and create encryption keys that will be used to protect your data in BigQuery, Cloud SQL, and Cloud Storage.

Configure the services to use CMEK for encrypting data at rest, ensuring compliance with your organization's security policies.

Cloud External Key Manager (EKM):

Cloud EKM allows you to use keys managed by an external key management provider to encrypt data in Google Cloud services.

Integrate your external key management system with Google Cloud using supported protocols and APIs.

Configure your data warehouse services to use the external keys for encryption, ensuring that key management is handled outside of the Google Cloud environment.

Key Access Justifications:

Enable Key Access Justifications to provide visibility into why encryption keys are being accessed. This helps in monitoring and auditing key usage to ensure compliance and security.

Set up policies and logging to capture and review key access requests, providing insights into how and why keys are used.

Access Transparency and Approval:

Implement Access Transparency to gain visibility into Google’s access to your data and encryption keys.

Configure Access Approval to require explicit approval for Google support or engineering access to your data, adding an additional layer of security and control.

References:

Customer-Managed Encryption Keys (CMEK)

Cloud External Key Manager (EKM)

Key Access Justifications

Access Transparency

Access Approval

If you want to manage the key encryption keys used for your data at rest, instead of having Google manage the keys, use Cloud Key Management Service to manage your keys. This scenario is known as customer-managed encryption keys (CMEK). https://cloud.google.com/bigquery/docs/encryption-at-rest

https://cloud.google.com/load-balancing/docs/ssl - SSL Proxy Load Balancing is a reverse proxy load balancer that distributes SSL traffic coming from the internet to virtual machine (VM) instances in your Google Cloud VPC network.

https://cloud.google.com/logging/docs/export/troubleshoot#errors_exporting_to_cloud_storage

https://cloud.google.com/logging/docs/export/troubleshoot

Unable to grant correct permissions to the destination: Even if the sink was successfully created with the correct service account permissions, this error message displays if the access control model for the Cloud Storage bucket was set to uniform access when the bucket was created. For existing Cloud Storage buckets, you can change the access control model for the first 90 days after bucket creation by using the Permissions tab. For new buckets, select the Fine-grained access control model during bucket creation. For details, see Creating Cloud Storage buckets.

Objective: Ensure that the analytics workload on Compute Engine instances accessing Cloud Storage does not interact with the public internet.

Solution:

Private Google Access: This allows Compute Engine instances that only have internal IP addresses to reach Google APIs and services through a private connection without the need for a public IP address.

No Public IP Addresses: By avoiding public IP addresses for the instances, you ensure that they are not accessible from the internet and do not initiate internet connections.

Steps:

Step 1: Open the Google Cloud Console.

Step 2: Navigate to the VPC Network page and select the subnet where the Compute Engine instances are located.

Step 3: Enable Private Google Access for the subnet.

Step 4: Ensure that when launching the Compute Engine instances, no public IP addresses are assigned to them.

References:

Configuring Private Google Access

Preventing External IP Address Assignment

To comply with the regulation to keep instance logging data within Europe, specifically in the Netherlands (region europe-west4), you need to configure Cloud Logging to ensure that all logs are stored in a specified region. Here are the steps to achieve this:

Create a Cloud Storage Bucket:

Go to the Google Cloud Console.

Navigate to Cloud Storage and create a new bucket.

Set the location type to "Region" and select "europe-west4" as the region.

Configure Log Sink:

Go to the Logging section in the Google Cloud Console.

Create a new log sink and configure it to export logs to the Cloud Storage bucket you just created.

Ensure the sink includes all logs you want to keep within europe-west4.

Verify Configuration:

Ensure that the logs are being exported to the Cloud Storage bucket by checking the contents of the bucket.

This setup ensures that all your logging data remains within the specified region, adhering to compliance requirements.

References

Creating and Managing Log Sinks

Cloud Storage Locations

Configure Binary Authorization:

Binary Authorization is a deploy-time security control that ensures only trusted container images are deployed on GKE. It uses attestations to verify the authenticity and integrity of the images.

Enable Binary Authorization in your project through the Google Cloud Console or using the gcloud command-line tool.

Define attestation policies that specify which attestors (trusted entities) must sign off on container images before deployment.

Set Up Attestors:

Create and configure attestors that will sign the container images. This involves generating cryptographic keys and setting up trusted authorities.

Attestors can be configured to sign images based on criteria such as vulnerability scanning results, compliance checks, and other security policies.

Create a Custom Organization Policy Constraint:

Define an organization policy constraint that enforces Binary Authorization across your GKE clusters.

This custom constraint ensures that all clusters in the organization must adhere to the Binary Authorization policy, preventing the deployment of unsigned or unauthorized container images.

Implement and Enforce the Policies:

Apply the Binary Authorization policy and the organization policy constraint to your GKE clusters.

Regularly review and update the policies and attestation rules to align with your security and compliance requirements.

References:

Binary Authorization Documentation

Creating Attestors

Organization Policy Constraints

To delegate management of access control permissions to each business unit effectively, organizing projects into folders and assigning permissions to Google groups at the folder level allows for scalable and manageable access control. Using Google Cloud Directory Sync (GCDS) to synchronize users and groups from the on-premises directory service ensures that access controls are maintained and updated automatically as users change roles or leave the company.

Steps:

Organize Projects in Folders: Create a folder structure in the Google Cloud Resource Manager to organize projects by business unit.

Assign Permissions to Google Groups: Use IAM to assign necessary permissions to Google Groups at the folder level, ensuring each business unit can manage access controls for their own projects.

Synchronize Users and Groups: Use GCDS to sync users and group memberships from your on-premises directory service to Google Cloud Identity, ensuring that changes in the on-premises directory are reflected in Google Cloud.

References:

Google Cloud Resource Manager

Google Cloud Directory Sync

https://cloud.google.com/blog/products/g-suite/7-ways-admins-can-help-secure-accounts-against-phishing-g-suite

https://www.duocircle.com/content/email-security-services/email-security-in-cryptography#:~:text=Customer%20Login-,Email%20Security%20In%20Cryptography%20Is%20One%20Of%20The%20Most,Measures%20To%20Prevent%20Phishing%20Attempts &text=Cybercriminals%20love%20emails%20the%20most,networks%20all%20over%20the%20world.

Encrypt non-sensitive data with Google default encryption:

Google Cloud automatically encrypts data at rest using AES-256 by default. This minimizes key management complexity for non-sensitive data as it is handled entirely by Google.

No additional setup is required for default encryption, ensuring low latency access to the encrypted data.

Encrypt sensitive data with Cloud Key Management Service (Cloud KMS):

Cloud KMS allows you to create and manage cryptographic keys in a centralized cloud service.

To meet the requirement of scheduling key rotation, configure Cloud KMS to automatically rotate keys on a regular schedule (e.g., every 90 days).

Control the region where the keys are stored by selecting the appropriate key ring location during key creation. This ensures compliance with data residency requirements.

Cloud KMS provides low-latency access to keys, ensuring minimal impact on data access performance.

References:

Cloud Key Management Service Documentation

Encryption at Rest in Google Cloud

https://cloud.google.com/logging/docs/access-control#considerations roles/logging.privateLogViewer (Private Logs Viewer) includes all the permissions contained by roles/logging.viewer, plus the ability to read Data Access audit logs in the _Default bucket.

"In order to be able to keep using the existing identity management system, identities need to be synchronized between AD and GCP IAM. To do so google provides a tool called Cloud Directory Sync. This tool will read all identities in AD and replicate those within GCP. Once the identities have been replicated then it's possible to apply IAM permissions on the groups. After that you will configure SAML so google can act as a service provider and either you ADFS or other third party tools like Ping or Okta will act as the identity provider. This way you effectively delegate the authentication from Google to something that is under your control."

To handle significant traffic spikes and potentially malicious IPs, you can use Google Cloud Armor to configure rate-based bans. This approach allows you to automatically ban clients that exceed a predefined request rate, protecting your application from potential denial-of-service attacks.

Access Google Cloud Console: Log in to your Google Cloud Console.

Navigate to Google Cloud Armor: Go to the "Security" section and select "Google Cloud Armor".

Create Security Policy: Create a new security policy or edit an existing one. Add a new rule to the policy.

Configure Rate-Based Ban: Set the action to rate_based_ban. Define the rate limit (e.g., requests per second) and set the ban_duration_sec parameter to the desired time interval.

Apply the Policy: Apply the security policy to your backend service or load balancer.

Monitor and Adjust: Monitor the traffic patterns and adjust the rate limits and ban durations as necessary to balance security and availability.

References:

Google Cloud Armor Documentation

Rate Limiting with Cloud Armor

Understanding Unmanaged Users:

Unmanaged users are those who have created Google Cloud accounts using their company email addresses outside of the organization's management (e.g., through GCDS).

Challenge:

The goal is to bring these unmanaged accounts under your company's control without disrupting their existing accounts and access.

Using the Transfer Tool:

Google provides a transfer tool specifically designed to migrate unmanaged users to a managed state.

This tool allows administrators to invite unmanaged users to join the organization's Google Cloud Identity or Google Workspace account.

Steps to Use the Transfer Tool:

Step 1: Access the transfer tool from the Google Admin console.

Step 2: Identify the unmanaged users using their email addresses.

Step 3: Send invitations to these users to transfer their accounts.

Step 4: Users accept the invitations, allowing their accounts to be managed under the organization's domain.

Benefits:

This method ensures a smooth transition for users without losing access to their existing data and services.

It aligns with best practices for managing user accounts in a corporate environment.

References:

Migrate unmanaged users

Google Cloud Directory Sync

Multiple network interfaces. The simplest way to connect multiple VPC networks through a virtual appliance is by using multiple network interfaces, with each interface connecting to one of the VPC networks. Internet and on-premises connectivity is provided over one or two separate network interfaces. With many NGFW products, internet connectivity is connected through an interface marked as untrusted in the NGFW software.

https://cloud.google.com/architecture/best-practices-vpc-design#l7

This architecture has multiple VPC networks that are bridged by an L7 next-generation firewall (NGFW) appliance, which functions as a multi-NIC bridge between VPC networks. An untrusted, outside VPC network is introduced to terminate hybrid interconnects and internet-based connections that terminate on the outside leg of the L7 NGFW for inspection. There are many variations on this design, but the key principle is to filter traffic through the firewall before the traffic reaches trusted VPC networks.

Google Cloud Armor helps to protect applications from DDoS attacks and web application firewall (WAF) threats like XSS and SQLi. To use Google Cloud Armor security policies, certain requirements must be met:

External Load Balancers: Google Cloud Armor is specifically designed to work with external HTTP(S) load balancers, which handle traffic at the edge of the Google Cloud network. This type of load balancer provides a global frontend that can distribute traffic to various backends.

Load Balancing Scheme: The backend service associated with the Google Cloud Armor policy must have an EXTERNAL load balancing scheme. This scheme allows the service to accept traffic from outside the Google Cloud network, which is necessary for applying security policies effectively at the network edge.

These requirements ensure that Google Cloud Armor can inspect and filter incoming traffic before it reaches your web application's backend services, providing an additional layer of security against common web vulnerabilities.

References

Google Cloud Armor Documentation

External HTTP(S) Load Balancing Overview

To comply with FIPS 140-2 for the messaging app, you need to ensure that both data at rest and data in transit are encrypted according to the standard. Using customer-managed encryption keys (CMEK) ensures that you have control over the encryption keys, and BoringSSL is a library that meets FIPS 140-2 standards for encrypting data in transit.

Steps:

Encrypt Local SSDs: Modify the instance template for the Managed Instance Group (MIG) to use customer-managed encryption keys (CMEK) for encrypting Local SSDs.

Enable BoringSSL: Update the application to use the BoringSSL library for all instance-to-instance communication to ensure that all data in transit is encrypted according to FIPS 140-2 standards.

References:

Google Cloud: Customer-managed encryption keys (CMEK)

BoringSSL documentation

https://gsuite.google.com/learn-more/security/security-whitepaper/page-1.html

Shared responsibility “Security of the Cloud” - GCP is responsible for protecting the infrastructure that runs all of the services offered in the GCP Cloud. This infrastructure is composed of the hardware, software, networking, and facilities that run GCP Cloud services.

To organize GCP projects based on different business units and manage IAM permissions, you should create an organization node and assign folders for each business unit. This approach allows you to logically separate projects under folders and apply IAM policies at the folder level.

Step-by-Step:

Create Organization Node: Ensure that your GCP account is linked to an organization.

Create Folders for Business Units:

Navigate to the GCP Console > IAM & Admin > Resource Manager.

Create a folder for each business unit under the organization node.

Move Projects to Folders:

Move existing projects into the respective folders according to the business unit.

Set IAM Policies:

Assign IAM roles and permissions at the folder level to manage access for each business unit independently.

Monitor and Manage: Use Cloud Audit Logs and other GCP tools to monitor the activities and ensure compliance with the organization’s policies.

References:

Creating and Managing Folders

Managing IAM Policies

Objective: Ensure private communication between application tiers in different GCP Organizations.

Solution: Use VPC peering to enable private communication without traversing the public internet.

Steps:

Step 1: Open the Google Cloud Console.

Step 2: Navigate to the VPC Network Peering page.

Step 3: Create a new VPC peering connection in the project hosting the application tier.

Step 4: Specify the VPC network in the other organization (hosting the storage tier) to peer with.

Step 5: Accept the peering request in the other project.

Step 6: Configure the necessary routes and firewall rules to allow traffic between the peered VPC networks.

VPC peering allows you to connect two VPC networks privately and directly, ensuring that traffic between them does not traverse the public internet.

References:

GCP VPC Peering Documentation

VPC Network Peering Guide

To reduce the scope of systems subject to PCI audit standards, segregate the cardholder data environment (CDE) into a separate GCP project. This ensures that only the project containing the CDE will be subject to PCI DSS compliance, reducing the audit scope for other projects.

Create Separate GCP Project:

Go to the Cloud Console, navigate to IAM & Admin > Manage Resources.

Click "Create Project" and set up a new project for the CDE.

Migrate CDE:

Transfer the systems processing, storing, or transmitting cardholder data to the new project.

Apply PCI DSS Controls:

Implement PCI DSS required controls on the new project.

Use appropriate security measures such as firewalls, access controls, and encryption.

References:

Google Cloud and PCI DSS

Creating and Managing Projects

To ensure that data is encrypted while in use by the virtual machines (VMs) and enforce this policy across your organization, you should use Confidential VM instances. Here are the steps:

Enable Confidential VM:

Ensure that Confidential VMs are available in your selected regions and enabled for your project.

Set Organization Policy:

Implement an organization policy to enforce the use of Confidential VM instances for all VMs across your organization.

Use the Google Cloud Console or the gcloud command-line tool to set this policy. Example command:

gcloud resource-manager org-policies set-policy my_policy.yaml

Example my_policy.yaml:

name: organizations/1234567890/policies/compute.requireConfidentialCompute spec: rules: - enforce: true

Verify and Monitor:

Ensure that all newly created VMs across your organization are Confidential VMs.

Regularly monitor compliance through the Google Cloud Console and set up alerts if non-compliant VMs are created.

Benefits:

Data Encryption in Use: Confidential VMs ensure that data is encrypted not just at rest and in transit but also while in use.

Policy Enforcement: Organization policies provide a way to enforce security configurations across all projects under your organization.

References

Confidential Computing Documentation

Creating and Managing Organization Policies

Set up a Dedicated Interconnect link between the on-premises environment and Google Cloud:

Dedicated Interconnect provides a direct physical connection between your on-premises network and Google's network, which is ideal for high-throughput, low-latency connections.

Request a Dedicated Interconnect from the Google Cloud Console, specifying the required bandwidth and location.

Once provisioned, set up the connection on your on-premises router and configure the BGP sessions to exchange routes with Google Cloud.

Configure private access using the restricted.googleapis.com domains in on-premises DNS configurations:

Configure your on-premises DNS server to resolve Google APIs to restricted.googleapis.com. This ensures that the traffic stays within the Google network and is not exposed to the public internet.

Update your DNS settings to use restricted.googleapis.com for the necessary API endpoints.

This setup ensures that all Google Cloud API traffic is routed through the private link and subject to VPC Service Controls for additional security and compliance.

References:

Dedicated Interconnect Overview

Configuring DNS to use restricted.googleapis.com

Rewriting the objects in-place within the same bucket, specifying the new CMEK for encryption, allows you to re-encrypt the data without downloading and re-uploading it, thus minimizing costs and time.

https://cloud.google.com/storage/docs/encryption/using-customer-managed-keys

To protect your web application from threats like malware by implementing TLS interception for incoming traffic, configuring a Secure Web Proxy with TLS offloading at the load balancer is an effective approach.​

Option A: By configuring a Secure Web Proxy, you can offload TLS traffic at the load balancer, inspect the decrypted traffic for threats such as malware, and then forward the inspected traffic to your web application. This approach ensures that encrypted traffic is securely analyzed without compromising the security of the data in transit.​

Option B: An internal proxy load balancer is designed for distributing traffic within a private network and may not support TLS interception capabilities required for inspecting incoming traffic from external sources.​

Option C: Hierarchical firewall policies in Google Cloud are used to enforce security rules across your organization but do not provide TLS interception capabilities.​

Option D: VPC firewall rules control traffic to and from VM instances based on specified rules but do not have the capability to perform TLS interception or traffic inspection.​

Therefore, Option A is the most suitable solution, as it allows for TLS interception through a Secure Web Proxy, enabling the inspection of incoming encrypted traffic to detect and mitigate threats like malware before the traffic reaches your web application.​

References:

Secure Web Proxy Overview

Cloud Load Balancing Overview

Rotating a user-managed Service Account key involves creating a new key, updating your application to use the new key, and then deleting the old key to maintain security. Here’s the step-by-step process:

Create a New Key: Use the Google Cloud Console or gcloud command-line tool to create a new key for the service account. This generates a new key pair and provides you with the private key.

gcloud iam service-accounts keys create new-key-file.json --iam-account=YOUR_SERVICE_ACCOUNT_EMAIL

Update Application: Update your application configuration to use the new key. This might involve replacing the old key file with the new one or updating the environment variables or configurations that point to the key file.

Delete the Old Key: Once you have confirmed that the application is working correctly with the new key, delete the old key from the service account to ensure it cannot be used for unauthorized access.

gcloud iam service-accounts keys delete OLD_KEY_ID --iam-account=YOUR_SERVICE_ACCOUNT_EMAIL

This process ensures that your service account keys are regularly rotated, reducing the risk of key compromise.

References

Managing Service Account Keys

Service Account Key Rotation

To provide temporary write access to a Cloud Storage bucket with the minimum permissions necessary, you should:

Identify the Compute Engine instance’s default service account: Each Compute Engine instance has a default service account that is used to interact with other Google Cloud services.

Assign the storage.objectCreator role: This predefined IAM role grants permissions to create objects in a Cloud Storage bucket, which is sufficient for temporary write access. It does not grant permissions to read or delete objects, thus adhering to the principle of least privilege.

Avoid using full permissions or long-lived keys: Options A and C suggest using broader permissions than necessary or embedding long-lived keys, which could pose a security risk if compromised.

Service account impersonation (Option D) is not necessary for this task and would be more appropriate for scenarios where you need to assume a different identity with different permissions.

References:

Google Cloud documentation on IAM roles for Cloud Storage, which lists the storage.objectCreator role as providing permissions to create objects without granting full administrative access to the bucket1.

Best practices for access control in Cloud Storage recommend using the least privilege necessary and avoiding the use of long-lived service account keys2.

To fulfill the requirements of preserving logs for 12 years and ensuring data residency within European boundaries, the best approach is to use Google Cloud's operations suite (formerly Stackdriver) with a custom log bucket configured in the desired region.

Configure Cloud Logging Agent:

Install and configure the Cloud Logging agent on your Compute Engine instances. This agent collects logs from your application and system and sends them to Google Cloud's operations suite.

Create a Custom Log Bucket:

In the Cloud Logging interface, create a custom log bucket in the EUROPE-WEST1 region. This bucket will store your logs and can be configured with a custom retention period.

Set Custom Retention Policy:

Configure the retention policy for the custom log bucket to 12 years. This ensures that all logs are preserved for the required duration.

Ship Logs to the Custom Log Bucket:

Modify the logging configuration to direct logs from the Cloud Logging agent to the custom log bucket. This can be done through the logging configuration settings in the Cloud Console or by updating the agent configuration files.

This solution minimizes overhead by using managed services and ensures cost-effectiveness by leveraging Cloud Logging's built-in capabilities for log storage and retention management.

References

Cloud Logging Documentation

Creating and Managing Logs Buckets

Objective: Migrate ongoing data backup and disaster recovery solutions to GCP.

Solution: Use Cloud Storage with scheduled tasks and gsutil.

Steps:

Step 1: Set up a Cloud Interconnect to ensure stable networking connectivity between the on-premises environment and GCP.

Step 2: Create a Cloud Storage bucket to store backups.

Step 3: Use gsutil, a command-line tool for Cloud Storage, to create scripts for data transfer.

Step 4: Schedule these scripts using cron jobs or another scheduling tool to automate the backup process.

Using Cloud Storage with scheduled tasks and gsutil ensures efficient and reliable backup and disaster recovery while leveraging stable connectivity provided by Cloud Interconnect.

References:

Cloud Storage Documentation

gsutil Tool Documentation

Cloud Interconnect Documentation

This is a Customer-supplied encryption keys (CSEK). We generate our own encryption key and manage it on-premises. A KEK never leaves Cloud KMS.There is no KEK or KMS on-premises. Encryption at rest by default, with various key management options https://cloud.google.com/security/encryption-at-rest

Firewall Rule Analysis: Analyze the existing VPC firewall rules to identify any rules that might allow traffic between VM instances based on the same service account.

Priority Check: Check the priority of these rules. A rule with a priority lower than 1000 (such as 999) will take precedence over your tag-based rules.

Service Account Configuration: Since your VM instances are deployed without any service account customization, they are likely using the default service account. A firewall rule allowing traffic between instances using this default service account will override the tag-based rules if it has a higher priority.

Testing and Validation: Disable or adjust the priority of the rule with priority 999 to test if the tag-based segmentation works correctly. Validate that the traffic is segmented according to your intended configuration. References:

Google Cloud - VPC Firewall Rules

Google Cloud - Service Accounts

To migrate the current data backup and disaster recovery solutions to GCP while keeping the production environment on-premises, the most scalable and cost-efficient solution is using Google Cloud Storage with scheduled tasks and the gsutil command.

Setup Cloud Storage: Create a Cloud Storage bucket to store the backups.

Go to the Cloud Console and navigate to Cloud Storage.

Click "Create bucket" and follow the prompts to configure the storage bucket.

Install gsutil: Ensure gsutil is installed on the on-premises servers.

gsutil is a command-line tool for interacting with Cloud Storage.

Follow the installation guide here.

Create Backup Script: Write a script to upload data to Cloud Storage using gsutil.

#!/bin/bash gsutil -m cp -r /path/to/local/backup gs://your-bucket-name

Schedule Backup Task: Use a scheduling tool like cron on Linux to run the backup script at regular intervals.

Edit the crontab file with crontab -e and add an entry like:

References:

Cloud Storage Documentation

gsutil Documentation

To restrict access to the MySQL instance to only the frontend application while other VMs are present in the subnets, creating an ingress firewall rule is the most appropriate approach. This rule will specifically allow traffic from subnet A (where the frontend application resides) to the MySQL instance in subnet B on port 3306, using network tags to target the specific MySQL VM.

Steps:

Create Network Tags: Apply a network tag (e.g., "data-tag") to the MySQL VM in subnet B.

Create Ingress Firewall Rule: Configure an ingress firewall rule with the following settings:

Source IP Range: Subnet A's IP range.

Target Tag: "data-tag".

Allowed Protocol/Ports: TCP:3306 (for MySQL).

This setup ensures that only instances in subnet A can communicate with the MySQL instance on port 3306.

References:

Google Cloud: Configuring firewall rules

https://cloud.google.com/logging/docs/export/aggregated_sinks#supported-destinations

You can use aggregated sinks to route logs within or between the same organizations and folders to the following destinations: - Another Cloud Logging bucket: Log entries held in Cloud Logging log buckets.

VPC Peering is between organizations not between Projects in an organization. That is Shared VPC. In this case, both projects are in same organization so having VPC Service Controls around both projects with necessary rules should be fine.

https://cloud.google.com/vpc-service-controls/docs/overview

To ensure that only trusted container images are deployed on Cloud Run, you can implement Binary Authorization, which is a deploy-time security control that ensures only trusted images are used.

Set Up Binary Authorization:

Navigate to the Google Cloud Console.

Go to Security > Binary Authorization.

Configure the policy to include attestors that verify your trusted images.

Enable Binary Authorization on Cloud Run:

Go to the Cloud Run service.

Enable Binary Authorization on your existing Cloud Run services by selecting the appropriate Binary Authorization policy.

Set Organization Policy:

Go to the Organization Policies page in the Google Cloud Console.

Add a constraint for constraints/run.allowedBinaryAuthorizationPolicies.

Specify the list of allowed Binary Authorization policy names to enforce across your organization.

These steps ensure that any container image deployed on Cloud Run is validated against the specified Binary Authorization policies, preventing untrusted images from being deployed.

References:

Binary Authorization Documentation

Enabling Binary Authorization on Cloud Run

To minimize the usage of service account keys and implement Workload Identity Federation (WIF) with your on-premises identity provider, you can use a workload identity pool integrated with your corporate Active Directory Federation Service (ADFS). This setup allows your on-premises Windows-based applications to authenticate to Google Cloud APIs without using long-lived service account keys.

Set Up a Workload Identity Pool:

In the Google Cloud Console, go to IAM & Admin > Workload Identity Federation.

Create a new workload identity pool.

Configure the pool to trust your corporate ADFS by specifying the federation provider details.

Create a Workload Identity Provider:

Within the created pool, set up a new provider for ADFS.

Configure the provider with the necessary details such as the issuer URL and credentials.

Configure Impersonation Rules:

Set up rules to allow principals in the workload identity pool to impersonate specific Google Cloud service accounts.

This is done by specifying the identity provider and the conditions under which the service accounts can be impersonated.

Update Applications:

Modify your on-premises applications to use the configured ADFS authentication to obtain tokens.

These tokens can then be exchanged for Google Cloud access tokens to interact with Google Cloud APIs securely.

By setting up the workload identity pool and configuring impersonation rules, you achieve secure authentication without needing to distribute and manage service account keys.

References:

Workload Identity Federation Documentation

Federating On-Premises Identities to Workload Identity Federation

When configuring SAML-based Single Sign-On (SSO) in an organization that's using Active Directory, the general steps would involve setting up a SAML profile, specifying the necessary URLs for sign-in and sign-out processes, uploading an X.509 certificate for secure communication, and setting up the Entity ID and Assertion Consumer Service (ACS) URL in the Identity Provider (which in this case would be Active Directory).

By generating a key in your on-premises environment and storing it in an HSM that you manage, you're ensuring that the key material is fully under your control. Using the key as an external key in Cloud KMS allows you to use the key with Google Cloud services without having the key stored on Google Cloud. Activating Key Access Justifications (KAJ) provides a reason every time the key is accessed, and you can configure the external key system to reject unauthorized access attempts.

When dealing with VPC Service Controls (VPC SC), it's important to ensure that only authorized resources can access sensitive data and services. To allow a resource in Project B to access Pub/Sub in Project A without compromising security, you should configure an ingress policy for the service perimeter in Project A.

Identify the Service Account: Determine the service account in Project B that requires access to the Pub/Sub topic in Project A.

Configure Ingress Policy:

Go to the Google Cloud Console.

Navigate to Security > VPC Service Controls.

Select the service perimeter for Project A.

Add an ingress rule specifying the service account from Project B and allowing it access to the necessary Pub/Sub resources.

Define Conditions: Ensure that the ingress policy adheres to the principle of least privilege, granting only the necessary permissions to collect messages from the Pub/Sub topic.

Save and Apply: Save the policy and apply the changes to enforce the new access controls.

This approach maintains the security boundaries set by VPC SC while enabling the required access from Project B to Project A.

References:

VPC Service Controls Documentation

Configuring Ingress Policies

To keep track of "who did what, where, and when?" within GCP projects, the administrator should focus on Admin Activity logs and Data Access logs. Here’s a detailed explanation of why these two log streams are essential:

Admin Activity Logs:

These logs capture administrative actions performed in your Google Cloud resources. This includes actions like creating, modifying, or deleting resources.

Admin Activity logs provide detailed information about the user who performed the action, the resource that was affected, the action performed, and the timestamp.

Data Access Logs:

These logs capture read and write operations on data within your Google Cloud services. This includes actions like accessing or modifying data stored in databases, storage buckets, etc.

Data Access logs help track the access patterns of users and services to sensitive data, providing insights into who accessed which data and when.

Steps to Enable and Access Logs:

Navigate to the Google Cloud Console.

Go to Logging in the left-hand menu.

Enable Admin Activity and Data Access logs if not already enabled.

Use Logs Explorer to filter and view specific logs based on your requirements.

By monitoring both Admin Activity and Data Access logs, administrators can gain comprehensive visibility into the actions performed on their GCP resources and data, ensuring robust security and compliance tracking.

References:

Google Cloud Logging Documentation

Audit Logs Overview

Objective: Ensure that a Cloud Storage bucket in Project A can only be readable from Project B and prevent data access or copying to Cloud Storage buckets outside the network, even with correct credentials.

Solution: Use VPC Service Controls to create a security perimeter.

Steps:

Step 1: Open the Google Cloud Console.

Step 2: Navigate to the VPC Service Controls page.

Step 3: Create a new service perimeter.

Step 4: Add Project A and Project B to the service perimeter.

Step 5: Include Cloud Storage service in the perimeter configuration.

Step 6: Define access levels to ensure that only resources within the perimeter can access the Cloud Storage bucket.

By setting up a VPC Service Controls perimeter, you can enforce security boundaries that restrict data access and movement to within defined projects, providing an extra layer of protection beyond IAM permissions.

References:

VPC Service Controls Overview

Configuring VPC Service Controls

https://cloud.google.com/access-transparency Access approval Explicitly approve access to your data or configurations on Google Cloud. Access Approval requests, when combined with Access Transparency logs, can be used to audit an end-to-end chain from support ticket to access request to approval, to eventual access.

Objective: Identify the layers of the stack the customer shares responsibility for in a shared security responsibility model for IaaS.

Solution: Understand the shared responsibility model.

Explanation:

Network Security: Customers are responsible for configuring network security, such as setting up firewalls, managing VPCs, and ensuring secure network traffic.

Access Policies: Customers are responsible for managing access policies, including IAM roles and permissions, to ensure only authorized users can access resources.

In IaaS, the cloud provider is typically responsible for the underlying infrastructure, while the customer is responsible for securing their applications and data on the cloud.

References:

Shared Responsibility Model

Google Cloud Security Overview

Managing IAM permissions at the KeyRing level is more efficient and scalable compared to managing them at the individual Key level. By creating a single KeyRing and placing all encryption keys within it, you can apply uniform IAM permissions to the entire KeyRing, simplifying the management of permissions.

Steps:

Create a KeyRing: Set up a single KeyRing in Cloud KMS for all the encryption keys required for the persistent disks.

Create Encryption Keys: Generate the necessary encryption keys within this KeyRing.

Set IAM Permissions: Assign IAM roles and permissions to the KeyRing to manage access control at this level, ensuring that all keys within the KeyRing inherit these permissions.

References:

Google Cloud: Cloud Key Management Service (KMS)

Managing access to resources
